Description
KitchenAid KVUB606DSS 36" Under-the-Cabinet Hood Features:
This is a beautiful addition to your kitchen, and it helps to keep it clean too. KitchenAid's 36" under-the-cabinet hood has a dishwasher-safe grease filter which helps capture steam, grease and odors that are created when cooking, so don't worry about that. You can focus on your delicious cuisine which is highlighted with the keen LED task lights. It has four different speed settings for the fan, and the fan can be programmed to turn itself off while you go enjoy your meal.
- 600 CFM/65,000 BTU Threshold - Allows installation over any KitchenAid regular 36" or 30" range or cooktop, and some commercial-style cooking surfaces with outputs up to 65,000 BTU
- Perimeter Ventilation - Increases ventilation system efficiency by pulling air from the edges of the hood and speeding up the movement of air at the center, allowing it to efficiently handle up to a 65,000 BTU total output
- Programmable Off Function - Can be set to automatically turn off after a period of time
- LED Task Lights - Provide extra lighting over the cooking surface to help in the cooking process
- 4-Speed Electronic Touch Control with LED Display - Provides sleek, visual confirmation of your ventilation selections, settings, and filter status
- Whisper Quiet System at 44 dBA (1.3 sones) at Low Speed - Ensures that the ventilation system operates at a quiet level so it can be used while entertaining; at maximum speed, sound level is 68 dBA (7.0 sones)
- Dishwasher Safe Grease Filters - Filter reduces steam, grease, and odor to help avoid contact with ceilings and countertops; the design increases filtration by obstructing the path of vented air to help capture more steam, grease, and odors as they are drawn through the vent
- Easy In-line Conversion - Converts from a traditional set-up to an in-line blower installation for an even more quiet operation; metal box purchase required
Download User Guide & Installation Instruction |
Specifications:
Controls |
|
| Control Type | Electronic Touch |
Details |
|
| Hood Type | Under-the-Cabinet |
| Material | Stainless Steel |
| Number of Night Light Settings | 0 |
| Number of Task Light Settings | 1 |
| Number of Vent Speeds | 4 |
| Task Lighting | Yes |
Dimensions |
|
| Product Dimension WxDxH (inch) | 36" x 19 3/4" x 9" |
| Carton Height | 24 |
| Gross Weight | 44.5 |
| Carton Depth | 13 |
| Carton Width | 39 |
| Net Weight | 33.07 |
General |
|
| Hood & Vent Features | Perimeter Ventilation |
Ventilation Details |
|
| Auto Function | Auto On |
| Blower Type | Centrifugal |
| Cfm Motor Class | 585 |
| Duct Direction | Vertical |
| Duct Outlet Size | 6 |
| Duct Type | Round |
| Filters | Grease Filters |
| Night Light | Yes |
| Night Light Type | N/A |
| Sones High Speed Horizontal | 8.5 |
| Sones High Speed Vertical | 7.5 |
| Sound Max Speed | 7 |
| Sound Max Speed (sones) | 7 |
| Sound Min Speed | 1.3 |
| Sound Min Speed (db(a) | 44.1 |
| Sound Min Speed (sones) | 1.3 |
| Task Light Type | LED |
| Venting | Exterior or Recirculating |
